HPE 455886-B21 10Gb SFP+ LR Transceiver Maximum Distance 10km

Overview of 455886-B21 10GBASE-LR SFP+ Transceiver Module:

The HPE 455886-B21 is a high-performance 10GBASE-LR SFP+ optical transceiver designed for long-distance, high-bandwidth connectivity in data centers, enterprise networks, cloud platforms, and HPE BladeSystem deployments.

Engineered to meet SFP+ MSA, IEEE 802.3ae, and 10GbE Long-Reach (LR) standards, this module delivers reliable 10 Gbps links over single-mode fiber (SMF) with a reach of up to 10 kilometers.

It features a 1310 nm DFB laser, low power consumption, and full Digital Diagnostics Monitoring (DDM/DOM) for real-time optical parameter reporting.

The module supports hot-swap operation and integrates seamlessly with HPE switches, servers, and storage platforms that accept 10G SFP+ LR optics.

Key Features:

1. 10GbE Connectivity: Supports data rates up to 10.3125 Gbps.
2. Long-Range Capability: Transmits data up to 10 km on 9/125µm Single-Mode Fiber (SMF).
3. Hot-Swappable: Allows for installation without powering down the host device, minimizing downtime.
4. Digital Optical Monitoring (DOM/DDM): Real-time monitoring of transceiver temperature, laser bias current, transmitted optical power, and received optical power.
5. MSA Compliant: Fully adheres to the SFP+ Multi-Source Agreement (SFF-8431).

SMF Optical Transceiver Technical Specifications:

HPE 455886-B21 Compatibility & Applications:

This transceiver is designed for rigorous compatibility testing with HPE hardware.

Primary Applications:

• Data Center Core to Edge connectivity.
• Inter-building or Campus Backbones (Long haul).
• Storage Area Network (SAN) uplinks.

Typical Compatible Hardware:

• HPE BladeSystem: c-Class c3000 / c7000 Enclosures.
• Network Adapters:
  • HPE NC550SFP Dual Port 10GbE Server Adapter
  • HPE NC523SFP 10Gb 2-port Server Adapter
  • HPE Ethernet 10Gb 2-port 530SFP+ / 560SFP+ Adapters
• HPE ProLiant Servers: Gen8, Gen9, and Gen10 Series (with SFP+ cages).
